（L） EQUAL ANGLE
Dimensions and Sectional Properties（1）ASTM A36/A6M-14
| Inch specifications | Inch specifications | Unit | Inch specifications | Inch specifications | Unit |
| side width | side width | Weight | side width | side width | Weight |
| side width side thickness(inch) | side width side thickness(inch) | (kg/m) | side width side thickness(inch) | side width side thickness(inch) | (kg/m) |
| L1-3/4×1-1/4×1/8 | 44.5*31.8*3.2 | 1.833 | L5×3-1/2×5/16 | L127*89*7.9 | 12.9 |
| L1-3/4×1-1/4×3/16 | 44.5*31.8*4.7 | 2.414 | L5×3-1/2×3/8 | L127*89*9.5 | 15.4 |
| L2×1-1/4×3/16 | 51*31.8*4.7 | 2.92 | L5×3-1/2×1/2 | L127*89*12.7 | 20.2 |
| L2×1-1/4×1/4 | 51*31.8*6.3 | 3.798 | L6×3-1/2×5/16 | 152*89*7.9 | 14.5 |
| L2-1/2×1-1/2×3/16 | 64*38*4.8 | 3.6 | L6×3-1/2×3/8 | 152*89*9.5 | 17.3 |
| L2-1/2×1-1/2×1/4 | 64*38*6.4 | 4.8 | L6 × 3-1/2 × 1/2 | 152*89*12.7 | 22.7 |
| L3×2×3/16 | 76*51*4.8 | 4.6 | L6×4×5/16 | L152*102*7.9 | 15.3 |
| L3×2×1/4 | 76*51*6.4 | 6.1 | L6×4×3/8 | L152*102*9.5 | 18.2 |
| L3×2×5/16 | 76*51*7.9 | 7.4 | L6×4×7/16 | L152*102*11.1 | 21.2 |
| L3×2-1/2×3/16 | L76*64*4.8 | 5.1 | L6×4×1/2 | L152*102*12.7 | 24.0 |
| L3×2-1/2×1/4 | L76*64*6.4 | 6.7 | L6×4×9/16 | L152*102*14.3 | 26.8 |
| L3×2-1/2×5/16 | L76*64*7.9 | 8.3 | L6×4×5/8 | L152*102*15.9 | 29.6 |
| L3×2-1/2×3/8 | L76*64*9.5 | 9.8 | L7×4×3/8 | L178*102*9.5 | 20.2 |
| L3-1/2×2-1/2×1/4 | L89*64*6.4 | 7.3 | L7×4×7/16 | L178*102*11.1 | 23.4 |
| L3-1/2×2-1/2×5/16 | L89*64*7.9 | 9.0 | L7×4×1/2 | L178*102*12.7 | 26.5 |
| L3-1/2×2-1/2×3/8 | L89*64*9.5 | 10.7 | L7×4×5/8 | L178*102*15.9 | 32.7 |
| L3-1/2×2-1/2×1/2 | L89*64*12.7 | 13.9 | L7×4×3/4 | L178*102*19 | 38.8 |
| L3-1/2×3×1/4 | L89*76*6.4 | 8.0 | L8×4×1/2 | L203*102*12.7 | 29.0 |
| L3-1/2×3×5/16 | L89*76*7.9 | 9.8 | L8×4×9/16 | L203*102*14.3 | 32.4 |
| L3-1/2×3×3/8 | L89*76*9.5 | 11.7 | L8×4×5/8 | L203*102*15.9 | 36.0 |
| L3-1/2×3×1/2 | L89*76*12.7 | 15.1 | L8×4×3/4 | L203*102*19.0 | 42.5 |
| L4×3×1/4 | 102*76*6.4 | 8.6 | L8×4×7/8 | L203*102*22.2 | 49.3 |
| L4×3×5/16 | 102*76*7.9 | 10.7 | L8×4×1 | L203*102*25.4 | 55.4 |
| L4×3×3/8 | 102*76*9.5 | 12.6 | L8×6×1/2 | L203*152*12.7 | 34.1 |
| L4×3×1/2 | 102*76*12.7 | 16.4 | L8×6×9/16 | L203*152*14.3 | 38.1 |
| L5×3×1/4 | 127*76*6.4 | 9.8 | L8×6×5/8 | L203*152*15.9 | 42.2 |
| L5×3×5/16 | 127*76*7.9 | 12.1 | L8×6×3/4 | L203*152*19 | 50.1 |
| L5×3×3/8 | 127*76*9.5 | 14.5 | L8×6×7/8 | L203*152*22.2 | 57.9 |
| L5×3×7/16 | 127*76*11.1 | 16.7 | L8×6×1 | L203*152*25.4 | 65.5 |
| L5×3×1/2 | 127*76*12.7 | 19.0 | |||
| L5×3-1/2×1/4 | L127*89*6.4 | 10.4 | |||
